Description

Alpha Geo Matrix II Lite

Alpha Geo Matrix II Lite generasi terbaru yang dirancang untuk memberikan solusi survei yang ringkas, akurat, dan efisien. Dengan desain yang kompak dan ringan, perangkat ini sangat ideal untuk berbagai aplikasi survei, mulai dari pemetaan lahan, konstruksi, hingga pemantauan infrastruktur.

Jual GPS Geodetik Alpha Geo Matrix II Lite

Jual GPS Geodetik Alpha Geo Matrix II Lite

Fitur Unggulan:

• Teknologi GNSS Multi-Konstelasi
  Mendukung GPS, GLONASS, Galileo, dan BeiDou untuk akurasi maksimal di berbagai kondisi lingkungan.
• Desain Kompak & Portabel
  Mudah dibawa dan digunakan di lapangan tanpa mengorbankan performa.
• Pengolahan Data Real-Time (RTK & PPK)
  Memberikan hasil cepat dengan ketelitian tinggi dalam survei.
• Baterai Tahan Lama
  Dirancang untuk penggunaan jangka panjang tanpa gangguan.
• Konektivitas Canggih
  Dilengkapi dengan Bluetooth, Wi-Fi, dan port komunikasi fleksibel untuk integrasi yang mudah dengan berbagai perangkat.

Spesifikasi GNSS Matrix II Lite :

Performance specification
Satellite signals tracked simultaneously
Channels 1408
Cold start <60 s
Hot start <15 s
Positioning output rate 1Hz-20Hz

GPS: L1 C/A, L2C, L2P, L5 GLONASS: L1, L2, L3
BEIDOU: B1, B2, B3, B1C, B2a, B2b
GALILEO: El/E5a/E5b/E6
QZSS: L1/L2/L5/L6
SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

Signal Reacquisition <1s
RTK Initialization time <5s
Initialization Reliability >99.99%
Time accuracy 20 ns

Positioning1
Static GNSS surveying
Horizontal: +(2.5mm + 0.5ppm)
Vertical: ±(5mm + 0.5ppm)

RTK Surveying
Horizontal: +(8mm + 1.0ppm)
Vertical: +(15mm + 1.0ppm)

HARDWARE
PHYSICAL
Material Magnesium alloy
Dimensions 120mm*72mm(without bottom connector 20mm)
weight 0.76kg
Operating temperature -40°C to +75°C
Storage temperature -55°C to +85°C
Protection IP IP67 dust proof, protected from 30min immersion to depth of 1m
Shock Survive 2 m drop onto the concrete
Vibration MIL-STD-810G
Humidity 100%, condensing

IMU

Supported, 4D IMU initialization in 3 seconds IMU
update rate 400Hz IMU
accuracy <2.5cm within 30° IMU
tilt compensation 0-120° IMU

ELECTRICAL
Power 9~24V DC external power
USB Type-C fast charging Support
Battery capacity Internal 7000mAh lithium-ion battery

Working Time
Network Mode >24h
Radio Reception >18h
Radio Transmission >8h

Communication & Data Storage
I/O interface 5pin Lemo port, TNC port

RADIO MODEM
internal radio TX/RX internal module
internal radio frenquency 410-470 MHZ
Communication protocols Alphatalk15, Transparent transmission /TT450S/SOUTH

Bluetooth
Fully integrated Bluetooth V4.0, range ≤ 50m

Data format
Differential data RTCM2.X, RTCM3.X
GPS output data format NMEA 0183s RTK, Binary code
static data format RINEX

Storage
8GB internal memory, supports cyclic storage; with ability to collect over one year raw observation based on 5 seconds interval

Others
System integration
OS system Intelligent LINUX operating system
Supported controllers All android devices with supported software

Design
Key one button
Indicator Power indicator, data link indicator, satellite indicator, Bluetooth indicator

ITEM PEMBELIAN :

Matrix II Lite Base
Matrix II Lite Base Rover
Controller Alpha Geo S60III
Radio External Harxon
Alumunium Tripod
Pole Carbon
Tribrach Adapter
Garansi 12 Bulan
FREE Training JABODETABEK
